Description
Building on the advanced Magneto X linear motor technology, Peopoly has developed Magneto PET-CF Filament—a high-performance PET-based carbon fiber composite filament designed for precision, durability, and superior mechanical properties. Optimized for Magneto X and other 3D printers, this material delivers outstanding strength, dimensional stability, and ease of use, making it an ideal choice for both professionals and advanced makers.
Payment & Security
Your payment information is processed securely. We do not store credit card details nor have access to your credit card information.
Estimate shipping
Print Parameters
- Nozzle Temperature: 280-320°C
- Recommended Nozzle Diameter: 0.4-1.0mm (hardened steel or higher grade)
- Recommended Build Surface: PEI or coat with PVP glue stick
- Build Plate Temperature: 60-80°C
- Raft Separation Distance: 0.08-0.12mm
- Cooling Fan Speed: OFF
- Print Speed: 30-120mm/s
- Keep it Dry: Important
Material Characteristics
Melting Temperature(°C): 225
Tensile Stress at Break (MPa): 65
Young’s Modulus (MPa): 4680
Elongation at Break(%): 2.9
Charpy Impact Strength (KJ/m^2): 7
Bending Strength (MPa): 95
Bending Modulus (MPa): 4450
Vicat softening temperature(°C): 220
Glass Transition Temperature: 135
IZOD Impact (Notched 72F) kJ/m: 36
Heat Deflection Values(°C): 80.5 / 91.5
Filament Density g/cm3: 1.3
Superior Strength and Rigidity
Reinforced with carbon fiber, Magneto PET-CF offers significantly higher tensile strength and stiffness compared to standard PET. Ideal for structural components, mechanical parts, and load-bearing applications.
Excellent Dimensional Stability
Low warping and shrinkage ensure highly precise and repeatable prints. Maintains its shape even in demanding conditions, making it great for functional prototypes and end-use parts.
High Heat and Chemical Resistance
Withstands temperatures up to 120°C, making it suitable for automotive, industrial, and engineering applications. Resistant to chemicals, oils, and solvents, ensuring durability in harsh environments.
Lightweight Yet Durable
The carbon fiber infusion reduces weight while maintaining exceptional strength. Perfect for aerospace, robotics, and lightweight structural components.
Smooth and Easy Printing
Less prone to clogging, thanks to a refined formulation that optimizes flow and adhesion. Great interlayer bonding, ensuring seamless and crack-free prints.
Storage and Handling:
Although PET has low moisture absorption, it's advisable to store the filament in a sealed package with desiccant to prevent moisture uptake. If the filament absorbs moisture, dry it at 90°C for 4-6 hours before use.
Enhanced Heat Performance Through Annealing
Experience even higher thermal resistance with our PET-CF filament through a simple annealing process. Post-print annealing at 90°C for 4 hours can significantly improve the heat deflection temperature (HDT) and increase material hardness. This thermal treatment optimizes the crystalline structure of PET, resulting in enhanced thermal stability and mechanical properties ideal for high-temperature applications.
Application
✅ Automotive and Aerospace: Strong, lightweight parts that resist high temperatures.
✅ Engineering and Prototyping: Reliable material for structural and functional prototypes.
✅ Manufacturing and Industrial Use: Tough and precise components for demanding environments.
✅ Robotics and Drones: High-strength, low-weight parts for moving assemblies.
✅ Sporting Equipment: Durable and rigid materials for impact-resistant applications.
