Description
First Desktop FFF 3D Printer with Magnetic-Based Linear Motor System
Magneto X features Peopoly's proprietary MagXY magnetic linear motor system for the X and Y axes, achieving unprecedented repeatability of 3 microns. Based on familiar fused filament fabrication technology, the Magneto X goes beyond traditional belts and pulleys, enabling high-speed, artifact-free, truly precise 3D printing at the desktop – powered by magnets.
Specification:
Motion System: MagXY
Movement Precision: 3um
Max Print Speed: Max 800mm/s
Max Travel Speed: 1500mm/s
Maximum Acceleration: 22000mm/s²
Print Volume: 400 x 300 x 300 mm
[Related News]:
*Price does not include VAT or customs fees from importing countries.
*Watch the video and scroll down for further information.
Payment & Security
Your payment information is processed securely. We do not store credit card details nor have access to your credit card information.
Estimate shipping
MagXY Motion System-No Belts and Pulleys
Magneto X features Peopoly's proprietary MagXY magnetic linear motor system for the X and Y axes, achieving unprecedented repeatability of 3 microns.
This motion system delivers top-tier accuracy and speed without belts or pulleys. Experience fewer print artifacts and less downtime, all while saving on long-term costs.
Magneto Linear Motor
The clean, simplified design of the MagXY linear motor system simplifies tasks like extruder replacement, with no belts to disconnect or obstruct access. Its low rail friction extends lifespan and reduces calibration needs. Motor auto disengagement prevents extensive damage if the extruder encounters an object.
Max 800 mm/s Print Speed
Magneto X's high-speed printing is made possible by its low-friction linear motor.
- Max 800 mm/s at 0.2mm layer height (0.4mm nozzle)
- Max Travel Speed: 1500 mm/s
- Acceleration 22000 mm/s
True Closed Loop Control
The Magneto X employs a true closed-loop control system for real-time adjustments and corrections during the printing process. This ensures unparalleled accuracy and precision in print outcomes while minimizing the risk of print failures. The system actively monitors and adjusts the motor's position, keeping your print jobs consistently high-quality.
Lancer Extrusion System: High Torque and Speed
Equipped with 90 Newtons of force and a pull speed of 30 mm/s, the Lancer system ensures efficient material delivery for high-speed printing. Its optimized melt zone design allows for a peak flow rate of 60 mm^3/s, achieving quick prints without sacrificing quality.
Harden Steel Nozzle with Swappable Melt Zones
Features E3D V6 volcano style nozzle compatibility (Reprap M6) for a range of nozzle types. The default 0.4mm nozzle is hardened steel, while the included 0.6mm nozzle is also. The system also offers optional swappable melt zones with different lengths, enhancing plastic melting, enabling faster flow rates, and ensuring consistent printing.
Optimized Cooling for Unmatched Print Speeds
Experience unparalleled speed without sacrificing quality, thanks to our innovative cooling system. Equipped with dual 13000 rpm 4015 ball-bearing fans and an additional 8000 rpm 3010 ball-bearing fan for the heat sink, our setup is designed to cool your prints efficiently—even at the fastest printing speeds.
Load Cell Sensor for Precise Auto-Leveling
The load cell sensor measures variations in the surface height of the build platform, providing data that allows for dynamic Z-axis adjustments. This ensures optimal first-layer printing and adhesion. The system utilizes a 48-point grid for comprehensive leveling across the entire build surface.
Broad Material Compatibility
Equipped with a 300°C hot end, the printer accommodates a wide range of materials, including PLA, PETG, ABS, ASA, and Nylon-Carbon Fiber.
Filament Runout Detection for Continuous Printing
Includes a filament sensor that continuously monitors material levels, minimizing the risk of print failures due to material depletion.
Big Build Volume of 400x300x300mm
Magneto X offers a 400 x 300 x 300 mm build volume, a large Volume for More Possibilities.
Size:
- Print Volume: 400 x 300 x 300 mm (X/Y/Z) (15.75 × 11.81 × 11.81 in)
- Build Platform: 400 x 300 mm
- The external dimensions without the spool stand are 605*541*570mm.
- The outline dimensions of the machine with the consumable holder are approximate: length*width*height: 700*550*700mm
- The outline dimensions of the machine with Jetstream fan and consumable holder are approximate: length*width*height: 700*550*700mm
- The outline dimensions of the fully enclosed machine with Jetstream fan and consumable holder are approximate: length*width*height: 700*550*800mm
4 Independent Z-axis Design
4 independently driven Z axes support an extra-large heavy-duty build platform for more stability, and it is easier to get accurate leveling.
Fast Heating Build Plate
400x300mm custom design heavy-duty aluminum build plate with magnets on top ensures stable temperature during printing, powered by a 1000W AC supply, rapidly heated to 130 °C.
Removal and Flexible PEI
A removal, flexible, double-side PEI sheet allows easy print removal. With a texture that can be quickly mounted via magnetic force on the build platform to ensure prints stay on and a higher print success rate.
Klipper - Advanced 3D Printer Firmware
The Magneto X operates on Klipper firmware, a leading open-source platform also used in Voron Design printers and an expanding roster of industrial printers. Offering a data-rich display, robust features, and versatile connectivity, Klipper serves as the intelligent core of the Magneto X. Peopoly proudly sponsors the Klipper project.
Magneto X offers multiple connectivity options such as WiFi, Ethernet, Bluetooth, SD card offline mode, and more.
Orca Slicer - Seamless Klipper Integration
Orca Slicer is a powerful open-source slicing software, building upon prior projects to offer excellent calibration functions, an intuitive user interface, and granular control over the 3D printing process. Its seamless integration with Klipper enables live data feeds, real-time adjustments, and video monitoring. Peopoly is a proud sponsor of the Orca Slicer project.
Built-in 1080P 30FPS Camera
Allow for high-resolution capture of the printing process for both sharing, and detecting potential print issues.
Optional Acrylic Enclosures for Thermal Stability
Semi-clear, smoky-colored acrylic optional full enclosures are available to maintain a consistent printing environment for temperature-sensitive materials like ABS, Nylon, PC, and PETG. It is added to minimize heat loss for materials requiring higher, stable temperatures. This setup is crucial for printing with specific filament types and for minimizing noise.
Optional Jetstream-Style Side-Mounted Fan
This uniquely shaped fan allows cooling for extruders at very low noise by blowing right at the extrusion point and even at the full length of the entire build plate, no matter where the extruder moves.
7 in Color Touch screen
●Intuitive and user-friendly interface
●Enhanced visibility and readability
●Allow users to interact with the printer directly
●Live display of working status
Your Privacy, Our Priority
In an industry where cloud-based operations and encrypted logs are increasingly the norm, Peopoly Magneto X stands apart. We firmly believe your printer should be entirely your own. No forced cloud usage, no hidden data collection, and certainly no overbearing user agreements that claim rights over your creations. With Magneto X, you are free to print, upgrade, and innovate without worry.
Your creativity, your data, your privacy—we're committed to ensuring they remain in your hands.
Technology Specifications
- Body
Build Volume(WxDxH): 400x300x300 mm
- MagXY
MagXY motor encoder: Linear magnetic encoder
MagXY motor encoder accuracy: 1um
MagXY motor voltage,current : 48V, Rated current 3A
MagXY Drive Mode: Three-phase DC brushless
MagXY Closed-loop control: Torque, Speed, Position
- ToolHead
Hot End: All-Metal
Nozzle: Copper, Harden steel
Max Hot End Temperature: 300℃
Nozzle Diameter: 0.2mm and 0.6mm(option), 0.4mm(include)
Swappable Melt Zones: Three types of molten zones, short(include), standard(include), long(option)
Filament Diameter: 1.75mm
Filament Run Out Sensor: Yes
Load Cell Sensor: Yes
Acceleration Sensor: ADXL345
- Hot Bed
Build Plate Surface: PEI
Max Build Plate Temperature: 130℃
- Speed
Max Speed of Tool Head : 800mm/s
Max Acceleration of Tool Head: 22000 mm/s2
Shot Melt Zones Flow Rate: 35mm³/s
Standard Melt Zones Flow Rate: 45mm³/s
Long Melt Zones Flow Rate: 60mm³/s
- Cooling
Part Cooling Fan: 13000rpm
Hot End Fan:8000rpm
Jetstream Fan: Cooling cross-section width:400mm 2400rpm
- Filament
PLA,PETG,TPU,ABS,PET support
- Camera
Monition Camera: 1920x1080
- Physical Dimensions
Dimensions(WxDxH): 700 x 550 x 700 mm³
Net Weight: 28kg
- Electrical Requirements
Voltage: 110v&220v VAC
Max Power: 1000W(220v) Hot Bed+950W (48v&24v)
- Electronics
Display: 7inch IPS touch screen
Connectivity: Wifi, Lan port
Storage: 16GB High Speed TF Card
Motion Controller: BTT Octopus Pro 1.1(STM32H723)
Klipper Host: Orange Pi Zero2 H616
- Slicer
Slicer: OrcaSlicer, PrusaSlicer, Cura, SupperSlicer
Shipping
Are being shipped in order of purchase.
It depends on where you are. Shipping from an overseas warehouse will take 5-7 business days to arrive. Delivery details will be provided in your confirmation email.
Import taxes and duties are not included in the retail or order price and will vary depending on your location. Please check local regulations for more details.
Product
The Magneto X comes nearly ready to print; all you'll need to add is your choice of filament. We'd also recommend grabbing a few extras like an additional nozzle and a spare melt zone kit for quick swaps if needed. While Magneto X does require a bit of hands-on assembly—specifically the hotbed and control panel—it's pretty straightforward, involving just about ten screws in total. Happy printing!
Without the enclosure, the noise of the model cooling fan is about 45-50db when the speed is 80%, and the noise is about 50-60db when the speed is 100%. It is possible to replace the fan of the same model with lower noise, but generally speaking, the noise is related to the speed. Positive correlation, heat dissipation capacity is positively related to rotation speed, so the fan with low noise may not have enough heat dissipation capacity to support high-speed printing.
Jetstream Side Cooling can work with enclosures.
